Layla Sheets and Plates, based in Cairo, Egypt, has built a solid reputation as a top-notch manufacturer and supplier of high-quality Alloy 20 Sheets and Plates. This company focuses on crafting corrosion-resistant alloys that excel in acidic and chemical environments. Their Alloy 20 sheets and plates are well-known for their impressive strength, durability, and resistance to sulfuric acid, making them a go-to choice in the chemical, pharmaceutical, and food processing sectors. Layla Sheets and Plates is dedicated to providing high-precision products that maintain consistent quality, competitive pricing, and timely delivery both in Egypt and on the international stage.
The Alloy 20 Sheets and Plates are made up of nickel (32–38%), chromium (19–21%), iron (the balance), molybdenum (2–3%), copper (3–4%), and trace amounts of niobium for stabilization. This distinctive chemical makeup grants them exceptional resistance to corrosion, pitting, and crevice attack in acidic and chloride-rich environments. On the mechanical side, Alloy 20 boasts a tensile strength of around 620 MPa, a yield strength of 300 MPa, along with good ductility and formability, ensuring reliable performance even in tough operating conditions.
Specifications : ASTM B463 / ASME SB463
Width : 1000mm, 1219mm, 1500mm, 1800mm, 200mm, 2500mm, 3000mm, 3500mm, etc
Length : 200mm, 2440mm, 3000mm, 5800mm, 200mm, etc
Thickness : 0.3 mm to 120 mm
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Finish : Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form : Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange)
| STANDARD | WERKSTOFF NR. | UNS | EN | AFNOR |
| Alloy 20 | 2.4660 | N08020 | NiCr20CuMo | Z2NCUD31-20AZ |
| Grade | C | Mn | Si | S | Cu | Ni | Cr | Fe | Mo | P |
| Alloy 20 | 0.07 max | 2.00 max | 1.00 max | 0.035 max | 3.00 – 4.00 | 32.00 – 38.00 | 19.00 – 21.00 | 29.85 min* | 2.00 – 3.00 | 0.045 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Alloy 20 | 8.1 g/cm3 | 1443 °C (2430 °F) | Psi -80,000, MPa -551 | Psi – 35,000, MPa – 241 | 30 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Layla Sheets and Plates based in Alexandria, Egypt, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Alloy 20 Sheets and Plates offer exceptional advantages for demanding industrial environments. They provide superior resistance to corrosion, particularly in sulfuric acid and chloride-rich environments, reducing maintenance costs and extending equipment lifespan. Their excellent mechanical properties, including high strength and durability, enable reliable performance under high-stress conditions. Alloy 20’s resistance to pitting, crevice corrosion, and stress-corrosion cracking ensures safety and efficiency in chemical processing, pharmaceuticals, and marine applications. Additionally, they are versatile and easy to fabricate, making them a preferred choice for tanks, piping, and heat exchangers.
Yes, we offer custom sizes for Alloy 20 Sheets and Plates to meet specific project needs. Our team at Layla Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
Alloy 20 Sheets and Plates find extensive use in the chemical and petrochemical industries for crafting heat exchangers, reactors, evaporators, and storage tanks. They are particularly well-suited for handling sulfuric acid, phosphoric acid, and other aggressive chemicals. Moreover, their remarkable resistance to corrosion and contamination makes them valuable in food processing, pharmaceutical, and marine applications. With their excellent mechanical strength and ease of fabrication, Alloy 20 sheets and plates deliver long-lasting, dependable service in highly corrosive industrial settings.
