Layla Sheets and Plates, located in Cairo, Egypt, stands out as a top manufacturer and supplier of high-quality Monel K500 Foils. With a reputation for precision engineering and rigorous quality control, the company provides materials that adhere to international standards for strength, corrosion resistance, and durability. Each Monel K500 Foil is crafted using cutting-edge manufacturing techniques and premium raw materials, guaranteeing exceptional mechanical performance and reliability even in tough marine, chemical, and industrial settings. Layla Sheets and Plates caters to clients throughout Egypt and the Middle East, offering tailored thicknesses, sizes, and finishes to fulfill specific industrial and engineering needs.
Monel K500 Foils are nickel-copper alloys enhanced with aluminum and titanium, delivering remarkable mechanical strength while ensuring excellent corrosion resistance. This alloy showcases high tensile and yield strength, outstanding fatigue resistance, and dimensional stability across a broad temperature range. Additionally, Monel K500 Foils are highly weldable and formable, making them perfect for precise fabrication in demanding industrial applications.
| Standards | ASTM B127 / ASME SB127 |
| Thickness | 0.3 – 10.0mm & AS PER CUSTOMER’S REQUIREMENT |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm & AS PER CUSTOMER’S REQUIREMENT. |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm & AS PER CUSTOMER’S REQUIREMENT. |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard AS PER CUSTOMER’S REQUIREMENT. |
| Test Certificate | Chemical test, Fitting test, Alloy test, Radiography test, Macro and micro-test, Hydrostatic test, Impact test. |
| Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled (HR), Cold rolled (CR), SATIN (Met with Plastic Coated) etc. |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel K500 | 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20 % |
DIN 2.4375 Foils offer numerous advantages, including superior strength and excellent resistance to corrosion, especially in marine environments, acids, and alkalis. Their high tensile and yield strength ensure durability and reliability under extreme stress and high temperatures. Monel K500 foils also exhibit outstanding resistance to stress corrosion cracking, pitting, and oxidation, making them ideal for use in harsh conditions. Additionally, they maintain excellent mechanical properties at elevated temperatures. Their ease of fabrication and welding further enhance their versatility, making them suitable for applications in aerospace, chemical processing and marine industries.
| STANDARD | WERKSTOFF NR. | UNS | AFNOR | JIS | GOST | BS | EN |
| Monel k500 | 2.4375 | N05500 | – | – | – | – | – |
These foils find extensive use in marine engineering, aerospace, chemical processing, and desalination sectors. They are particularly suited for heat exchangers, pumps, valves, electronic components, and other equipment that come into contact with seawater or corrosive chemicals. Monel K500 Foils from Layla Sheets and Plates promise long-lasting durability, structural integrity, and dependable performance in critical industrial applications.
